Hobby 800 G / 400 V lathe Bernardo 03-11620
The turning lathe Hobby 800 G is serially equipped with a leadscrew for thread cutting and the automatic longitudinal and cross feed. The 12-step control gear allow a quick adjustment of the speed – not belt change necessary. The compact construction and the high own weight guarantees smooth running and precise work.
PROPERTIES
- Control gear allows easy and quick speed change
- High-quality tapered rollerbearings ensure high concentricity of spindle nose (≤ 0,015 mm)
- Powerful motor for high torque, speed range 70 – 1800 rpm
- Wide range of applications: precision mechanics, training and education, etc.
- Logically arranged feed setting allows easy, smooth adjustment
- Solid machine bed with inductive hardened and polished guideways
- Ideal for processing steel, non-ferrous metals and plastics
- Comes complete with leadscrew for thread cutting and automatic longitudinal and cross feed
- Apron features handwheels with fine scale
TECHNICAL SPECIFICATIONS
|
Distance between centers |
750 mm |
|
Center height |
165 mm |
|
Swing over bed |
330 mm |
|
Bed width |
160 mm |
|
Spindle bore |
38 mm |
|
Taper at spindle bore |
MT 5 |
|
Speed range |
(12) 70 - 1800 rpm |
|
Longitudinal feed |
(45) 0,0087 - 1,395 mm/rev. |
|
Cross feed |
(48) 0,018 - 0,296 mm/rev. |
|
Metric thread |
(17) 0,5 - 4 mm |
|
Inch thread |
(26) 8 - 40 threads/1“ |
|
Travel of tailstock sleeve |
75 mm |
|
Taper of tailstock sleeve |
MT 3 |
|
Motor power output S1 100% |
1,1 kW / 400 V |
|
Motor power input S6 40% |
1,5 kW / 400 V |
|
Machine dimension (W x D x H)* |
1370 x 680 x 1320 mm |
|
Weight approx. |
268 kg |
* without stand
STANDARD ACCESSORIES
- 3-jaw chuck 160 mm
- Cross slide with top support
- Dead center
- Change gears
- 4-way tool post holder
- LED machine light
- Chuck guard
- Splash guard
- Leadscrew cover
- Chip tray
- Stand
- Tools
