VBS 400 Vertical bandsaw Bernardo 04-1786
The vertical bandsaws of the VBS-series are designed for cutting of various materials (for example steel, plastics, non-ferrous materials etc.) The application area is predominantly targeted at general production, tool and jig making and for the production of punching and cutting tools.
PROPERTIES
- Complete with LED-display to allow for easy speed setting
- Solid grey cast-iron table – the large surface improves safety aspects
- Blade welding device, annealing device, shear and grinder come standard
- Complete with stepless speed adjustment
- Solidly constructed steel body ensures smooth running
- High-quality bandsaw blade guide guarantees precise results
- Convenient cutting of irregular shaped workpieces
- 3 mm bandsaw blades are optionally available for radius cutting
TECHNICAL SPECIFICATIONS
|
Cutting width |
400 mm |
|
Cutting height |
280 mm |
|
Working height |
970 mm |
|
Cutting speed |
15 - 260 m/min |
|
Bandsaw blade width |
3450 mm |
|
Table size |
3 - 16 mm |
|
Size of additional table |
600 x 550 mm |
|
Table tilting range (in 4 directions) |
-15° to +45° |
|
Motor power |
1,5 kW |
|
Blade welding device |
2,4 kVA |
|
Machine dimension (L x D x H) |
1080 x 880 x 1810 mm |
|
Weight approx. |
325 kg |
STANDARD ACCESSORIES
- Bandsaw blade
- Blade welding device with annealing device
- Working light
- Shear
- Grinder
- Chip brush
- LED digital readout
- Micro cooling system
- Frequency inverter
- Rip fence
